RATING CHARTS

400V 3 PHASE 50 Hz

kVA @ Temperature Rise / Ambient °C / 0.8 PF
Ambient Temperature	40°C	40°C	40°C	45°C	45°C	45°C	45°C	45°C	45°C	50°C	50°C	50°C	50°C
Ambient Temperature Rise	125°C	105°C	80°C	120°C	110°C	100°C	95°C	75°C	70°C	115°C	95°C	90°C	70°C
Society	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	ABS KR	ABS	KR	ABS KR
Model
ECP3 1S 4C	6.5	6	5.2	6.2	5.9	5.8	5.5	5	4.7	6	5.6	5.3	4.8
ECP3 2S 4C	8	7.5	6.4	7.7	7.3	7.2	6.8	6.1	5.8	7.4	7	6.5	6
ECP3 1L 4C	11	10	8.8	10.6	10	9.6	9.4	8.4	8	10.2	9.3	8.9	8.2
ECP3 2L 4C	13.5	12.5	10.8	13	12.3	12	11.5	10.4	9.9	12.6	11.6	10.9	10
ECP3 3L 4C	15	14	12	14.4	13.7	13.4	12.8	11.5	11	14	13	12.2	11.2
ECP28 1VS 4C	7.5	6.7	6	7.2	6.9	6.4	6.4	5.8	5.5	7	6.2	5.8	5.6
ECP28 2VS 4C	10	9.1	8	9.6	9.1	8.7	8.5	7.7	7.4	9.3	8.5	8.1	7.4
ECP28 1S 4C	12.5	11.6	10	12	11.4	11.1	10.6	9.6	9.2	11.6	10.8	10.1	9.3
ECP28 2S 4C	15	14.1	12	14.4	13.7	13.5	12.7	11.5	11	14	13.1	12.2	11.2
ECP28 3S 4C	17.5	16.5	14	16.8	16	15.8	14.9	13.4	12.8	16.3	15.3	14.2	13
ECP28 M 4C	20	18.5	16	19.2	18.2	17.8	17	15.4	14.6	18.6	17.2	16.2	14.9
ECP28 L 4C	25	23	20	24	22.8	22.1	21.3	19.2	18.3	23.3	21.4	20.3	18.6
ECP28 VL 4C	30	26	24	28.8	27.3	25	25.5	23	21.9	27.9	24.2	24.3	22.3
ECP32 1S 4C	37.5	35	30	36	34.3	33.6	32.1	28.8	27.9	34.9	32.6	30	27.9
ECP32 2S 4C	45	41	36	43.2	41	39.4	38.1	34.6	32.8	41.9	38.1	36.5	33.5
ECP32 1M 4C	50	48	40	48	46	46.1	43	38.4	37	46.5	44.6	41	37.2
ECP32 2M 4C	62.5	59.5	50	60	57.5	57.1	53.6	48	45.6	58.1	55.3	50.6	46.5
ECP32 1L 4C	75	67	60	72	69	64.3	64	57.6	55	69.8	62.3	61	55.8
ECP32 2L 4C	82.5	73.2	66	79.2	76.3	70.3	70.1	63.4	60.8	76.7	68.1	67	61.4
ECP34 1S 4C	87.5	79	70	84	79.3	75.8	74.1	67.2	63.8	81.4	73.5	71	65.1
ECP34 2S 4C	100	90	80	96	91.4	86.4	84.8	76.8	73.3	93	83.7	81	74.4
ECP34 1M 4C	125	112	100	120	114	108	106	96	91	116	104	101	93
ECP34 2M 4C	135	121	108	130	123	116	115	104	99	126	113	109	100
ECP34 1L 4C	150	136	120	144	137	131	128	115	110	140	126	122	112
ECP34 2L 4C	165	149	132	158	150	143	141	127	121	153	139	133	123

kVA @ Temperature Rise / Ambient °C / 0.8 PF
Ambient Temperature	40°C	40°C	40°C	45°C	45°C	45°C	45°C	45°C	45°C	50°C	50°C	50°C	50°C
Ambient Temperature Rise	125°C	105°C	80°C	120°C	110°C	100°C	95°C	75°C	70°C	115°C	95°C	90°C	70°C
Society	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	ABS KR	ABS	KR	ABS KR
Model
ECO38 1S 4C	180	170	144	173	164	163	153	138	131	167	158	146	134
ECO38 2S 4C	200	185	160	192	182	178	170	154	146	186	172	162	149
ECO38 1M 4C	225	207	180	216	205	199	191	173	164	209	193	182	167
ECO38 2M 4C	250	230	200	240	228	221	213	192	183	233	214	203	186
ECO38 1L 4C	300	275	240	288	273	264	255	230	219	279	256	243	223
ECO38 2L 4C	350	320	280	336	319	307	298	269	256	326	298	284	260
ECO40 1S 4C	400	370	320	384	364	355	340	307	292	372	344	324	298
ECO40 2S 4C	450	410	360	432	410	394	383	346	329	419	381	365	335
ECO40 3S 4C	500	450	400	480	455	432	425	384	365	465	419	405	372
ECO40 1L 4C	550	500	440	528	501	480	468	422	402	512	465	446	409
ECO40 2L 4C	625	564	500	600	568	541	530	480	457	581	525	506	465
ECO40 3L 4C	680	630	544	653	619	605	578	522	496	632	586	551	506
ECO40 VL 4C	750	690	600	720	683	662	638	576	547	698	642	608	558
ECO43 1S 4A	820	750	655	787	748	720	684	629	598	763	698	664	609
ECO43 2S 4A	930	850	744	893	846	816	791	714	679	865	791	753	692
ECO43 1M 4A	1025	950	820	984	933	912	870	787	748	953	884	830	763
ECO43 2M 4A	1150	1050	920	1104	1046	1008	977	883	840	1070	977	930	856
ECO43 2L 4A	1300	1200	1040	1248	1183	1152	1105	998	949	1209	1116	1053	967
ECO43 VL 4A	1400	1280	1120	1344	1274	1229	1190	1075	1022	1302	1190	1134	1042
ECO46 1S 4A	1500	1350	1200	1440	1365	1296	1275	1152	1095	1395	1256	1215	1116
ECO46 1.5S 4A	1650	1480	1320	1584	1502	1421	1403	1267	1205	1535	1376	1337	1228
ECO46 2S 4A	1800	1600	1440	1728	1638	1536	1530	1382	1314	1674	1488	1458	1339
ECO46 1L 4A	2100	1900	1680	2016	1911	1824	1785	1613	1533	1953	1767	1701	1562
ECO46 1.5L 4A	2300	2050	1840	2208	2093	1968	1955	1766	1679	2139	1907	1863	1711
ECO46 2L 4A	2500	2250	2000	2400	2275	2160	2125	1920	1825	2325	2093	2025	1860
ECO46 VL 4A	2800	2500	2240	2688	2548	2400	2380	2150	2044	2604	2325	2268	2083

450V 3 PHASE 60 Hz

kVA @ Temperature Rise / Ambient °C / 0.8 PF
Ambient Temperature	40°C	40°C	40°C	45°C	45°C	45°C	45°C	45°C	45°C	50°C	50°C	50°C	50°C
Ambient Temperature Rise	125°C	105°C	80°C	120°C	110°C	100°C	95°C	75°C	70°C	115°C	95°C	90°C	70°C
Society	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	ABS KR	ABS	KR	ABS KR
Model
ECP3 1S 4C	7.8	7.2	6.2	7.5	7.1	6.9	6.6	6	5.7	7.3	6.7	6.3	5.8
ECP3 2S 4C	9.6	9	7.7	9.2	8.7	8.6	8.2	7.4	7	8.9	8.4	7.8	7.2
ECP3 1L 4C	13.2	12	10.6	12.7	12	11.5	11.2	10.2	9.6	12.3	11.2	10.7	9.9
ECP3 2L 4C	16.2	15	13	15.6	14.7	14.4	13.8	12.5	11.8	15.1	14	13.1	12.1
ECP3 3L 4C	18	16.5	14.4	17.3	16.4	15.8	15.3	13.8	13.1	16.7	15.3	14.6	13.4
ECP28 1VS 4C	8.8	7.8	7	8.4	8	7.5	7.5	6.7	6.4	8.2	7.3	7.1	6.5
ECP28 2VS 4C	11.6	10.5	9.3	11.1	10.5	10.1	9.9	8.9	8.5	10.8	9.8	9.4	8.6
ECP28 1S 4C	14.4	13.2	11.6	13.8	13	12.7	12.2	11.1	10.5	13.4	12.3	11.7	10.8
ECP28 2S 4C	17.2	16.1	13.8	16.5	15.6	15.5	14.7	13.2	12.6	16	15	14	12.8
ECP28 3S 4C	20.1	18.8	16.1	19.3	18.2	18	17.1	15.5	14.6	18.7	17.5	16.3	15
ECP28 M 4C	23.5	21	18.8	22.6	21.8	20.2	20	18	17.5	21.9	19.5	19.4	17.5
ECP28 L 4C	28.8	26.5	23	27.6	26.2	25.4	24.5	22.1	21.1	26.8	24.6	23.3	21.4
ECP28 VL 4C	36	32	29	34.6	32.8	30.7	30.6	27.8	26.3	33.5	29.8	29.2	27
ECP32 1S 4C	44	42	35.2	42.2	40	40.3	37.7	33.8	32.5	40.9	39.1	35.6	32.7
ECP32 2S 4C	52	50	41.6	49.9	47.9	48	44.9	39.9	37.7	48.4	46.5	42.1	38.7
ECP32 1M 4C	60	58	48	57.6	55	55.7	51	46.1	44	55.8	53.9	49	44.6
ECP32 2M 4C	73.8	70.8	59	70.8	67.7	68	63.7	56.6	53.6	68.6	65.8	59.6	54.9
ECP32 1L 4C	86	81.5	68.8	82.6	78.2	78.2	73.3	66	62.5	80	75.8	69.4	64
ECP32 2L 4C	98	90.5	78.4	94.1	89.2	86.9	83.4	75.3	71.5	91.1	84.2	79.2	72.9
ECP34 1S 4C	105	95	84	101	96	91	90	81	76.7	98	88	85	78
ECP34 2S 4C	120	109	96	115	110	105	102	92	87.6	112	101	97	89.3
ECP34 1M 4C	145	130	116	139	132	125	123	111	106	135	121	117	108
ECP34 2M 4C	156	141	125	150	142	135	132	120	114	145	131	126	116
ECP34 1L 4C	175	157	140	168	159	151	149	134	128	163	146	142	130
ECP34 2L 4C	195	172	156	187	177	165	166	150	142	181	160	158	145

kVA @ Temperature Rise / Ambient °C / 0.8 PF
Ambient Temperature	40°C	40°C	40°C	45°C	45°C	45°C	45°C	45°C	45°C	50°C	50°C	50°C	50°C
Ambient Temperature Rise	125°C	105°C	80°C	120°C	110°C	100°C	95°C	75°C	70°C	115°C	95°C	90°C	70°C
Society	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	RINA DNV BV ABS KR CRS	LR	ABS KR	ABS	KR	ABS KR
Model
ECO38 1S 4C	220	205	176	211	200	197	187	169	161	205	191	178	164
ECO38 2S 4C	240	220	192	230	218	211	204	184	175	223	205	194	179
ECO38 1M 4C	270	250	216	259	245	240	232	207	197	251	233	220	201
ECO38 2M 4C	300	280	240	288	273	269	255	230	219	279	260	243	223
ECO38 1L 4C	350	320	280	336	319	307	298	269	256	326	298	284	260
ECO38 2L 4C	420	385	336	403	382	370	357	323	307	391	358	340	312
ECO40 1S 4C	465	425	372	446	423	408	395	357	339	432	395	377	346
ECO40 2S 4C	525	475	420	504	478	456	446	403	383	488	442	425	391
ECO40 3S 4C	590	530	472	566	537	509	502	453	431	549	493	478	439
ECO40 1L 4C	645	585	516	619	587	562	548	495	471	600	544	522	480
ECO40 2L 4C	728	657	583	699	662	631	620	560	530	677	611	590	542
ECO40 3L 4C	798	739	638	766	726	709	675	612	583	742	687	646	593
ECO40 VL 4C	900	830	720	864	819	797	766	691	657	837	772	729	670
ECO43 1S 4A	985	900	790	946	896	864	837	758	719	916	837	798	735
ECO43 2S 4A	1088	994	870	1044	991	954	924	835	795	1012	924	882	809
ECO43 1M 4A	1145	1048	916	1099	1043	1006	972	879	837	1065	975	928	852
ECO43 2M 4A	1368	1270	1094	1313	1245	1219	1163	1050	1000	1272	1181	1108	1017
ECO43 2L 4A	1521	1404	1217	1460	1384	1348	1293	1168	1110	1415	1306	1232	1132
ECO43 VL 4A	1700	1540	1360	1632	1547	1478	1445	1306	1241	1581	1432	1377	1265
ECO46 1S 4A	1755	1575	1404	1685	1597	1512	1492	1348	1281	1632	1465	1422	1306
ECO46 1.5S 4A	1930	1735	1544	1853	1756	1666	1641	1482	1409	1795	1614	1564	1436
ECO46 2S 4A	2105	1870	1684	2021	1916	1795	1789	1617	1537	1958	1739	1705	1566
ECO46 1L 4A	2455	2215	1964	2357	2234	2126	2087	1885	1792	2283	2060	1989	1827
ECO46 1.5L 4A	2690	2395	2152	2582	2448	2299	2287	2066	1964	2502	2227	2179	2001
ECO46 2L 4A	2920	2625	2336	2803	2657	2520	2482	2243	2132	2716	2441	2365	2172
ECO46 VL 4A	3220	2900	2576	3091	3019	2784	2742	2473	2423	2995	2697	2687	2396
